Build a 3-Agent Software Delivery Pipeline with Band SDK and AI/ML API

Build a 3-Agent Software Delivery Pipeline with Band SDK and AI/ML API

Most multi-agent demos assign tasks to agents in a fixed loop. This tutorial builds something closer to how real software teams work: a Planner agent scopes the feature, an Engineer agent writes and tests the code, and a Reviewer agent checks it — and all three coordinate in a shared Band room using @mentions, the same way a human team would use Slack.

By the end you will have three independent Python processes running on your machine, connected to the Band platform. Drop a feature request in the room and watch the pipeline run end-to-end: a plan lands in workspace/plan.md, working FastAPI code appears in workspace/app/, tests run automatically, and a review appears in workspace/review.md.

The full source code is on GitHub.

What you will build

A 3-agent software delivery pipeline with this structure:

Band platform (app.band.ai) — shared chat room
       |              |               |
  +---------+   +----------+   +----------+
  | Planner |   | Engineer |   | Reviewer |
  +---------+   +----------+   +----------+
       \              |              /
        \             |             /
         v            v            v
        workspace/ (shared local directory)
          plan.md, app/, review.md

Each agent is a band.Agent backed by a PydanticAIAdapter. Model calls go through AI/ML API via its OpenAI-compatible endpoint — no framework-specific model wiring needed. Agents coordinate by @mentioning each other in the Band room; all plan, code, and review content lives as files in workspace/.

Prerequisites

• Python 3.11 or higher
• A Band account with three remote agents created (one each for Planner, Engineer, and Reviewer) — each agent gives you an Agent ID and API key
• An AI/ML API account and API key
• Basic familiarity with Python and async code

Step 1: Clone the repo and install dependencies

git clone https://github.com/Stephen-Kimoi/band-3-agent-delivery-pipeline
cd band-3-agent-delivery-pipeline
python -m venv .venv
source .venv/bin/activate  # Windows: .venv\Scripts\activate
pip install -r requirements.txt

The requirements.txt installs the Band SDK with its PydanticAI adapter, plus pytest, fastapi, uvicorn, and httpx — the last three are needed because the Engineer agent writes and runs FastAPI tests:

Full file at requirements.txt:

band-sdk[pydantic-ai]
python-dotenv
fastapi
uvicorn
httpx
pytest

Step 2: Configure your AI/ML API key

cp .env.example .env

Open .env and paste your AI/ML API key:

Full file at .env.example:

OPENAI_API_KEY=your_aimlapi_key_here
OPENAI_BASE_URL=https://api.aimlapi.com/v1
DEFAULT_MODEL=openai-chat:deepseek/deepseek-chat-v3.1

Two things worth noting here.

Why OPENAI_API_KEY and OPENAI_BASE_URL? AI/ML API speaks the OpenAI Chat Completions protocol. PydanticAI's openai: model family reads these two standard environment variables and routes every call through AI/ML API automatically — no extra adapter code needed.

Why the versioned model ID? The unversioned deepseek-chat ID on AI/ML API returns plain text instead of making tool calls. The versioned deepseek/deepseek-chat-v3.1 ID calls tools correctly, which is essential here — agents write files and send messages via tools, not plain text replies. Use this ID (or openai-chat:gpt-4o-mini if you prefer OpenAI).

To use different models per agent, add per-role overrides:

PLANNER_MODEL=openai-chat:deepseek/deepseek-chat-v3.1
ENGINEER_MODEL=openai-chat:deepseek/deepseek-chat-v3.1
REVIEWER_MODEL=openai-chat:gpt-4o-mini

Step 3: Register your agents on Band

Go to app.band.ai and create three remote agents — name them Planner, Engineer, and Reviewer. Each one gives you an Agent ID and an API key.

cp agent_config.yaml.example agent_config.yaml

Paste each agent's credentials into agent_config.yaml:

Full file at agent_config.yaml.example:

planner:
  agent_id: ""
  api_key: ""

engineer:
  agent_id: ""
  api_key: ""

reviewer:
  agent_id: ""
  api_key: ""

agent_config.yaml is gitignored — it holds secrets and should never be committed.

Step 4: Understand the architecture

Before starting the agents, it helps to see how the three pieces fit together. Every agent shares the same bootstrap logic in agents/runner.py:

Full implementation in agents/runner.py, lines 38–60:

adapter = PydanticAIAdapter(
    model=model,
    custom_section=custom_section,          # the agent's system prompt
    additional_tools=[read_file, write_file, list_files, run_tests],
)

agent = Agent.from_config(
    agent_key,
    adapter=adapter,
    config_path=PROJECT_ROOT / "agent_config.yaml",
)

await agent.run()

Agent.from_config connects to Band using the credentials in agent_config.yaml. PydanticAIAdapter wraps a PydanticAI model and exposes four file-system tools to every agent:

Tool	What it does
read_file(path)	Read a file from workspace/
write_file(path, content)	Write a file to workspace/
list_files(path)	List files under a path in workspace/
run_tests(path)	Run pytest on a directory in workspace/ and return output

All paths are sandboxed to workspace/ — a path traversal check in tools.py prevents agents from reading or writing outside it. Full implementation in agents/tools.py.

The agents coordinate in Band chat using band_send_message (a Band-provided tool). The system prompt for each role tells it exactly when to send a message and who to @mention:

• Planner: receives the feature request, writes plan.md, then @mentions the Engineer
• Engineer: reads plan.md, writes app/main.py + app/test_main.py, runs tests, then @mentions the Reviewer
• Reviewer: reads the code and tests, writes review.md, then either approves or @mentions the Planner with revision requests

The key design rule: chat is for coordination, files are for content. Agents never paste plans or code into chat — they write to workspace/ and point others to the file path. This keeps the room readable and decouples communication from content.

Step 5: Start the three agents

Open three terminals. In each one, activate the virtual environment and start one agent:

Terminal 1 — Planner:

source .venv/bin/activate
python -m agents.planner

Terminal 2 — Engineer:

source .venv/bin/activate
python -m agents.engineer

Terminal 3 — Reviewer:

source .venv/bin/activate
python -m agents.reviewer

Each process connects to Band and waits in its agent's rooms. You should see a log line like:

2026-06-12 11:30:01 band.agent Starting planner agent (model=openai-chat:deepseek/deepseek-chat-v3.1)...

All three processes must be running before you send the first message.

Step 6: Create a Band room and send a feature request

In app.band.ai:

1. Create a new room
2. Add your three agents (Planner, Engineer, Reviewer) as participants
3. Send a message that @mentions Planner with a feature description:

@Planner We need a new FastAPI endpoint: POST /tasks to create a task
(title: str, done: bool = false) and GET /tasks to list all tasks, stored
in memory. Please write a plan.

Step 7: Watch the pipeline run

After you send the message, watch the room and your terminals. The pipeline runs in three handoff steps.

Planner's turn: The Planner reads your message, calls write_file to create workspace/plan.md with endpoints, acceptance criteria, and edge cases, then calls band_send_message to notify the Engineer:

@Engineer The plan is ready at plan.md. Please implement the POST /tasks
and GET /tasks endpoints with in-memory storage and write tests.

Engineer's turn: The Engineer calls read_file("plan.md"), implements workspace/app/main.py and workspace/app/test_main.py, then calls run_tests("app") to verify everything passes:

$ pytest app

test_main.py::test_create_task PASSED
test_main.py::test_list_tasks PASSED
test_main.py::test_list_empty PASSED

Once tests pass, the Engineer @mentions the Reviewer.

Reviewer's turn: The Reviewer reads the code and tests, calls write_file("review.md") with its findings, then either posts an approval or @mentions the Planner with revision requests.

A successful review looks like this in the room:

@Planner @human_participant

Implementation complete. review.md has been written.

Summary:
- POST /tasks creates a task with auto-incremented id, title, and done=false default ✓
- GET /tasks returns the full list ✓
- Tests cover creation, listing, and empty-list edge case ✓
- Status: APPROVED — no changes needed

Step 8: Run the generated app

Once the Reviewer approves, run the FastAPI app the Engineer wrote:

uvicorn workspace.app.main:app --reload

Open http://127.0.0.1:8000/docs to see the auto-generated Swagger UI. Test the endpoints:

# Create a task
curl -X POST http://127.0.0.1:8000/tasks \
  -H "Content-Type: application/json" \
  -d '{"title": "Write the tutorial"}'

# List tasks
curl http://127.0.0.1:8000/tasks

Swapping models

Swapping models is a one-line change in .env. No code changes needed — all three agents route through AI/ML API's OpenAI-compatible endpoint.

To switch all agents to GPT-4o Mini:

DEFAULT_MODEL=openai-chat:gpt-4o-mini

To give the Reviewer stronger reasoning:

PLANNER_MODEL=openai-chat:deepseek/deepseek-chat-v3.1
ENGINEER_MODEL=openai-chat:deepseek/deepseek-chat-v3.1
REVIEWER_MODEL=openai-chat:gpt-4o

AI/ML API supports hundreds of models through the same endpoint. See the AI/ML API model list for all available IDs.

Project layout

prototype/
├── agents/
│   ├── runner.py       — shared bootstrap: model wiring, tools, Band connection
│   ├── tools.py        — read_file / write_file / list_files / run_tests
│   ├── planner.py      — entrypoint: python -m agents.planner
│   ├── engineer.py     — entrypoint: python -m agents.engineer
│   └── reviewer.py     — entrypoint: python -m agents.reviewer
├── prompts/
│   ├── planner.md      — Planner system prompt
│   ├── engineer.md     — Engineer system prompt
│   └── reviewer.md     — Reviewer system prompt
├── workspace/          — shared scratch space (gitignored, created at runtime)
├── agent_config.yaml   — Band agent_id/api_key per role (gitignored)
└── .env                — AI/ML API key + model overrides (gitignored)

Frequently Asked Questions

Q: Can I add a fourth agent to the pipeline? Yes. Create a new agent on Band, add it to agent_config.yaml, write a system prompt in prompts/, and create a thin entrypoint (copy planner.py and change agent_key, prompt_file, and model_env_var). The runner bootstrap handles everything else. A natural extension is a QA agent that runs load tests after the Reviewer approves.

Q: What happens if an agent calls run_tests and the tests fail? The Engineer agent's system prompt tells it to fix the code and re-run tests before notifying the Reviewer. In practice the Engineer makes one or two revision passes before the tests go green. If tests keep failing, check your model ID — the unversioned deepseek-chat on AI/ML API does not make tool calls and will stall the pipeline.

Q: Why do agents use band_send_message instead of plain text replies? Band agents receive messages via WebSocket but their replies are only delivered to the room if sent through band_send_message. A plain text response from the underlying model goes nowhere — only tool calls are wired into the Band platform. The system prompt for each agent makes this explicit.

Q: Do all three agents need to be running at the same time? Yes. Band delivers @mention messages to whichever agents are connected at the time. If the Engineer is not running when the Planner sends its handoff, the message queues until the Engineer reconnects — but for a live demo, start all three before sending the first request.

Q: Can I use this pattern outside of software delivery? The Planner–Executor–Reviewer pattern transfers to any task with a clear plan → build → verify structure: content pipelines (Writer → Editor → Publisher), data pipelines (Extractor → Transformer → Validator), or research pipelines (Researcher → Analyst → Fact-checker). Swap the system prompts in prompts/ and the workspace tools as needed.

What to do next

Add more agents: Extend the pipeline with a dedicated QA agent that runs integration tests and a Deploy agent that ships the built app to a hosting provider.

Swap the workspace: The current workspace is a local directory shared between processes on the same machine. For distributed agents, replace tools.py with tools that read and write to a shared S3 bucket or a Git repository — the agent code and Band coordination logic stay identical.

Make it async: The current design is sequential — each agent waits for an @mention before starting. For larger features, the Planner could decompose the work and @mention multiple Engineers simultaneously, with the Reviewer collecting their outputs.

Explore more AI/ML API models: The pipeline defaults to DeepSeek V3.1 but any tool-calling model on AI/ML API works as a drop-in. Try openai-chat:claude-opus-4-8 for the Reviewer for stronger code analysis, or use openai-chat:gpt-4o-mini across the board to minimize costs.
