Building AI Trading Agents with On-Chain Identity: A Complete Guide

Part 1: What Is ERC-8004 and Why Does It Matter?

The problem: your AI agent is a ghost

You build a trading bot. It runs, it trades, it makes decisions. But from the blockchain's perspective, it doesn't exist. There's just a wallet address, no identity, no record of what the agent is, who operates it, or what it's supposed to do.

This creates real problems:

• No accountability: anyone can claim any wallet address is their "AI agent"
• No discoverability: other contracts can't verify they're talking to an authorized agent
• No reputation: the agent builds no on-chain history that others can trust

ERC-8004 solves this.

---

What ERC-8004 is

ERC-8004 is a standard for AI Agent Identity Registry on Ethereum. It defines a registry contract where agents can be registered with structured metadata, and every registration produces a unique, verifiable agentId.

Think of it like ENS (Ethereum Name Service), but for AI agents instead of human-readable names.

What gets stored on-chain

From contracts/AgentRegistry.sol L33–L41:

struct AgentRegistration {
    address operatorWallet;  // Owns the ERC-721 token, pays gas
    address agentWallet;     // Hot wallet the agent uses for signing
    string  name;
    string  description;
    string[] capabilities;   // e.g. ["trading", "analysis", "eip712-signing"]
    uint256 registeredAt;
    bool    active;
}

What you get back: agentId

When you call register(), the contract mints an ERC-721 token and returns its ID:

agentId = _nextAgentId++;   // auto-incrementing uint256
_mint(msg.sender, agentId); // ERC-721 mint — you own this token

This agentId (the ERC-721 token ID) becomes the agent's persistent on-chain identity — used for:

• Capital allocation in the agent Vault
• Risk validation in the Risk Router
• Cryptographic signing in EIP-712 checkpoints

---

Prerequisites

• Node.js 20+ installed
• Sepolia ETH (get from sepoliafaucet.com)
• Infura or Alchemy Sepolia RPC URL
• Kraken CLI installed (see Part 3)

---

Step 1: Clone the repo and install dependencies

git clone https://github.com/Stephen-Kimoi/ai-trading-agent-template
cd ai-trading-agent-template
npm install

---

Step 2: Configure your environment

cp .env.example .env

Fill in at minimum:

SEPOLIA_RPC_URL=https://sepolia.infura.io/v3/YOUR_KEY
PRIVATE_KEY=0xYOUR_OPERATOR_WALLET_PRIVATE_KEY

# Optional: separate hot wallet for signing. Defaults to PRIVATE_KEY.
AGENT_WALLET_PRIVATE_KEY=0xYOUR_HOT_WALLET_KEY

Two wallet roles:

Wallet	Role	Recommended
PRIVATE_KEY (operatorWallet)	Owns the ERC-721 token, pays gas	Cold wallet / hardware wallet
AGENT_WALLET_PRIVATE_KEY (agentWallet)	Signs TradeIntents + checkpoints at runtime	Separate hot wallet

For testing, the same key for both is fine.

---

Step 3: Deploy the five contracts

npx hardhat run scripts/deploy.ts --network sepolia

Output:

1/5 Deploying AgentRegistry (ERC-721)...
   AgentRegistry: 0xABC...
2/5 Deploying HackathonVault...
   HackathonVault: 0xDEF...
3/5 Deploying RiskRouter...
   RiskRouter: 0xGHI...
4/5 Deploying ReputationRegistry...
   ReputationRegistry: 0xJKL...
5/5 Deploying ValidationRegistry...
   ValidationRegistry: 0xMNO...

── Add these to your .env ──────────────────────────────────────────
AGENT_REGISTRY_ADDRESS=0xABC...
HACKATHON_VAULT_ADDRESS=0xDEF...
RISK_ROUTER_ADDRESS=0xGHI...
REPUTATION_REGISTRY_ADDRESS=0xJKL...
VALIDATION_REGISTRY_ADDRESS=0xMNO...
────────────────────────────────────────────────────────────────────

Copy all five addresses to your .env.

Note: If you're integrating with an existing deployment (e.g. a shared registry or vault someone else deployed), use those contract addresses instead and skip this step. Deploying your own contracts is recommended for local development and testing.

---

Step 4: Register your agent

npm run register

Output:

Operator wallet: 0xYourOperatorAddress
Agent wallet:    0xYourAgentWalletAddress
AgentRegistry:   0xABC...

[identity] Registering new agent on-chain (ERC-721 mint)...
[identity] Registration tx: 0xTXHASH...
[identity] Agent registered! Token ID (agentId): 0
[identity] Add to .env: AGENT_ID=0
[identity] Saved to agent-id.json

Agent registered!
agentId (ERC-721 token ID): 0

Add to .env:
  AGENT_ID=0

Setting default risk params on RiskRouter...
Risk params set: maxPosition=$500, maxDrawdown=5%, maxTrades/hr=10

Add AGENT_ID=0 (or whatever token ID you received) to your .env.

---

Step 5: Verify on Etherscan

Open Sepolia Etherscan → your AGENT_REGISTRY_ADDRESS → Events tab:

AgentRegistered
  agentId (token ID): 0
  operatorWallet:     0xYourOperatorAddress
  agentWallet:        0xYourAgentWalletAddress
  name:               AITradingAgent

You can also check the ERC-721 Transfers tab, you'll see the mint event transferring token ID 0 from the zero address to your wallet.

---

Why on-chain agent identity matters

1. The identity layer is already built

By using ERC-8004, every team's agent automatically gets a verifiable identity without having to invent their own scheme. The registry is the shared ground truth.

2. Reputation becomes composable

Because agentId is persistent and tied to on-chain activity, every trade, every checkpoint, every vault interaction is linked to that identity. Future systems could build reputation scores, whitelists, or risk tiers on top of this.

3. The scaffolding stays the same

This is the "reusable template" angle: the identity, reputation system, and validation scaffolding (ERC-8004 → Vault → RiskRouter → EIP-712) stay constant across teams. What changes is the strategy inside. Your agent's identity doesn't care if you're running a momentum strategy, an LLM, or a neural network.

---

The AgentRegistry contract

Here's the core registration function (contracts/AgentRegistry.sol L92–L120):

function register(
    address agentWallet,
    string calldata name,
    string calldata description,
    string[] calldata capabilities,
    string calldata agentURI
) external returns (uint256 agentId) {
    require(bytes(name).length > 0, "AgentRegistry: name required");
    require(agentWallet != address(0), "AgentRegistry: invalid agentWallet");

    agentId = _nextAgentId++;
    _mint(msg.sender, agentId);        // ERC-721 mint
    _setTokenURI(agentId, agentURI);

    agents[agentId] = AgentRegistration({
        operatorWallet: msg.sender,
        agentWallet: agentWallet,
        name: name,
        description: description,
        capabilities: capabilities,
        registeredAt: block.timestamp,
        active: true
    });

    walletToAgentId[agentWallet] = agentId;
    emit AgentRegistered(agentId, msg.sender, agentWallet, name);
}

Key properties:

• Mints an ERC-721 token: your agent identity is a transferable NFT
• Two wallet roles: operatorWallet (owns the token) and agentWallet (signs trades at runtime)
• Auto-incrementing agentId: starts at 0, stable and unique forever
• Emits an event: AgentRegistered(agentId, operatorWallet, agentWallet, name) — queryable on Etherscan

---

Part 2: Registering Your Agent On-Chain (ERC-721)

Why ERC-721?

Your agent's identity is an NFT. This means:

• agentId is a uint256 token ID, stable, unique, gas-efficient to store
• The token is transferable: sell a well-performing agent along with its on-chain reputation
• Standard ERC-721 interfaces mean wallets, marketplaces, and indexers understand it natively
• Token URI points to your Agent Registration JSON (metadata about capabilities and endpoints)

---

What the registration looks like under the hood

scripts/register-agent.ts L47 calls src/agent/identity.ts L46–L68:

const agentId = await getAgentId(operatorSigner, registryAddress, {
  name: "AITradingAgent",
  agentWallet: agentWallet.address,
  capabilities: ["trading", "analysis", "eip712-signing"],
  agentURI: "ipfs://...",  // or data URI
  ...
});

Which calls register() on the contract (contracts/AgentRegistry.sol L92–L120):

function register(
    address agentWallet,
    string calldata name,
    string calldata description,
    string[] calldata capabilities,
    string calldata agentURI
) external returns (uint256 agentId) {
    agentId = _nextAgentId++;
    _mint(msg.sender, agentId);   // <-- ERC-721 mint
    _setTokenURI(agentId, agentURI);
    // ... stores metadata
    emit AgentRegistered(agentId, msg.sender, agentWallet, name);
}

The token ID is auto-incrementing from 0. Your agentId is unique and permanent.

---

Template note

Why this matters: Once registered, your agentId is the identity anchor for everything your agent does, capital allocation, risk validation, EIP-712 checkpoint signing, and on-chain attestations. This is how agents build verifiable on-chain reputation over time. Swapping your strategy never touches this layer.

---

Part 3: Connecting to Kraken CLI

Why the CLI, not raw REST?

When building an AI trading agent, you want your code to stay focused on strategy and decision-making: not exchange plumbing. The Kraken CLI handles all of that automatically:

• Cryptographic nonce management (no clock drift issues)
• HMAC-SHA512 request signing (no manual auth code)
• Rate-limit retries (no 429 handling needed)
• Built-in paper trading sandbox (--sandbox flag)
• Built-in MCP server: exposes Kraken as structured tools for AI agents

---

Installing the Kraken CLI

# install script (Linux/macOS)
curl --proto '=https' --tlsv1.2 -LsSf https://github.com/krakenfx/kraken-cli/releases/latest/download/kraken-cli-installer.sh | sh

# check out the version
kraken --version

Add to your .env:

KRAKEN_API_KEY=your_api_key
KRAKEN_API_SECRET=your_api_secret
KRAKEN_SANDBOX=true          # start with sandbox!
KRAKEN_CLI_PATH=kraken       # only needed if binary isn't on PATH

---

Getting Kraken API keys

1. Log into kraken.com → choose Kraken Pro (Advanced trading)
2. Go to Settings → API and create a new key
3. Tick exactly these permissions:

Funds permissions

• ✅ Query — required for getBalance()

Orders and trades

• ✅ Query open orders & trades — required for getOpenOrders()
• ✅ Create & modify orders — required for placeOrder()
• ✅ Cancel & close orders — required if the agent needs to cancel orders

Leave everything else unchecked (no Deposit, Withdraw, Earn, Data, or WebSocket).

4. Copy the key + secret into .env

---

Using the CLI directly

The CLI is useful to verify your setup before running the agent:

# Check ticker (no auth needed)
kraken --json ticker --pair XBTUSD

# Check balance (requires API key)
kraken --json --api-key $KRAKEN_API_KEY --api-secret $KRAKEN_API_SECRET balance

# Paper trade (sandbox mode)
kraken --sandbox --json --api-key $KRAKEN_API_KEY --api-secret $KRAKEN_API_SECRET \
  order add --pair XBTUSD --type buy --ordertype market --volume 0.001

---

How the TypeScript client wraps the CLI

src/exchange/kraken.ts L64–L87 spawns the CLI as a subprocess:

private async run(subcommand: string[], isPrivate = false): Promise<unknown> {
  const args: string[] = [];
  if (isPrivate && !this.sandbox) {
    args.push("--api-key", this.apiKey, "--api-secret", this.apiSecret);
  }
  args.push(...subcommand);
  args.push("-o", "json");

  const { stdout } = await execFileAsync(KRAKEN_BIN, args, { timeout: 15000 });
  return JSON.parse(stdout.trim());
}

All three public methods use this:

// Fetch market data
const market = await kraken.getTicker("XBTUSD");
// → { price: 95420.5, bid: 95418, ask: 95423, volume: 1204, ... }

// Place order (paper trade in sandbox)
const result = await kraken.placeOrder({
  pair: "XBTUSD", type: "buy", ordertype: "market", volume: "0.001"
});
// → { txid: ["OTXID-..."], descr: { order: "buy 0.001 XBTUSD @ market" } }

---

MCP server mode (alternative)

The CLI ships with a built-in MCP server, the preferred integration for agents that already use the Model Context Protocol:

# Start the MCP server
kraken mcp serve --port 8080

Then use KrakenMCPClient in src/exchange/kraken.ts:

import { KrakenMCPClient } from "./src/exchange/kraken.js";
const kraken = new KrakenMCPClient(8080);

// Same interface as KrakenClient
const market = await kraken.getTicker("XBTUSD");

This is the cleanest approach for LangChain/Claude tool-use integrations, since the MCP server exposes Kraken operations as first-class tools.

---

Sandbox vs. live

Setting	Behavior
KRAKEN_SANDBOX=true	Paper trading — orders logged but not executed
KRAKEN_SANDBOX=false	Live trading — real funds, real orders

The agent reads this at startup. No code changes needed to switch modes.

---

Template note

Template note: The KrakenClient is the exchange adapter layer. Your strategy returns a TradeDecision — the agent loop calls placeOrder() automatically. You never touch the CLI directly. Swapping Kraken for a different exchange only requires replacing this one file.

---

Part 4: The Vault, Risk Router, and TradeIntent Pattern

The full flow

Strategy decision (TradeDecision)
       ↓
  Build TradeIntent struct
       ↓
  Sign with EIP-712 (agentWallet)
       ↓
  RiskRouter.submitTradeIntent(intent, signature)
       ├── verifies EIP-712 signature → agentWallet in AgentRegistry
       ├── checks nonce (replay protection)
       ├── checks deadline
       ├── validates risk params (position size, trade frequency)
       ├── emits TradeApproved or TradeRejected on-chain
       ↓ (if approved)
  Kraken CLI: placeOrder()
       ↓
  Vault tracks capital

Every step is on-chain. Every approval and rejection is a permanent event.

---

The TradeIntent struct

Instead of the agent directly calling Kraken, it first constructs a signed intent: a commitment to a specific trade that's been cryptographically authorized (contracts/RiskRouter.sol L35–L44):

struct TradeIntent {
    uint256 agentId;
    address agentWallet;       // must match AgentRegistry
    string  pair;              // e.g. "XBTUSD"
    string  action;            // "BUY" or "SELL"
    uint256 amountUsdScaled;   // USD * 100 (e.g. 50000 = $500)
    uint256 maxSlippageBps;    // max acceptable slippage
    uint256 nonce;             // replay protection
    uint256 deadline;          // Unix timestamp
}

The nonce increments with each approved intent, so an old signature can't be replayed.

---

Building and signing a TradeIntent (TypeScript)

src/onchain/riskRouter.ts L72–L145 handles this:

const riskRouter = new RiskRouterClient(routerAddress, agentWallet, SEPOLIA_CHAIN_ID);

// 1. Build intent (fetches current nonce from chain)
const intent = await riskRouter.buildIntent(
  agentId,
  agentWallet.address,
  "XBTUSD",
  "BUY",
  100,   // $100 USD
  { maxSlippageBps: 50, deadlineSeconds: 300 }
);

// 2. Sign with EIP-712 (agentWallet is the hot signing key)
const signed = await riskRouter.signIntent(intent, agentWallet);

// 3. Submit to RiskRouter
const result = await riskRouter.submitIntent(signed);

if (result.approved) {
  console.log("Trade approved — intentHash:", result.intentHash);
} else {
  console.warn("Trade rejected:", result.reason);
}

The intentHash is carried into the EIP-712 checkpoint, linking the checkpoint to the specific approved intent.

---

What the RiskRouter checks

1. deadline     — is the intent still valid?
2. nonce        — does it match the stored nonce (not replayed)?
3. signature    — does it recover to the registered agentWallet?
4. position size — is amountUsdScaled ≤ maxPositionSize?
5. trade frequency — are we within maxTradesPerHour?

Each check emits an event on Sepolia if it fails:

TradeRejected(agentId, intentHash, "Exceeds maxPositionSize")
TradeRejected(agentId, intentHash, "Intent expired")

If all checks pass:

TradeApproved(agentId, intentHash, amountUsdScaled)

---

Setting your risk params

You don't need to do this manually: npm run register already sets default risk params as part of registration (scripts/register-agent.ts L76–L83):

// Called automatically during npm run register
await router.setRiskParams(
  agentId,
  BigInt(50000),  // maxPositionUsdScaled: $500 max per trade (500 * 100)
  BigInt(500),    // maxDrawdownBps: 5%
  BigInt(10)      // maxTradesPerHour: 10
);

To change them later, use src/onchain/riskRouter.ts L183–L196:

await riskRouter.setRiskParams(
  agentId,
  500,    // maxPositionUsd: $500 per trade
  500,    // maxDrawdownBps: 5%
  10      // maxTradesPerHour
);

---

Template note

Why this matters: The TradeIntent pattern gives every trade a cryptographic proof of intent that was validated on-chain before execution. This is what makes agent behavior auditable and trustworthy: anyone can verify that a specific trade was approved by a specific registered agent against a defined risk policy, without having to trust the agent's own logs.

---

Part 5: Building the Explanation Layer

Why explainability matters for trading agents

When an agent makes a trade, two questions need answers:

1. For humans: Why did it do that?: in plain language, auditable after the fact
2. For machines: Can we verify it said what it claims to say?: cryptographically

This tutorial covers the first question. Part 6 covers the second.

---

The reasoning field in every decision

Every TradeDecision returned by your strategy must include a reasoning string (src/types/index.ts L30–L37):

interface TradeDecision {
  action: "BUY" | "SELL" | "HOLD";
  asset: string;
  pair: string;
  amount: number;
  confidence: number;
  reasoning: string;   // ← this is required
}

This is what your strategy should return for reasoning:

// Good: specific, auditable
"Price fell 1.2% over last 5 ticks while volume dropped 40% below average.
Bearish divergence — selling to reduce exposure. Risk: potential support at
$94,200 may reverse the move."

// Bad: too vague
"The market looks bad."

The reasoning field flows through three places automatically, once per tick (every 30 seconds by default):

Where	What you see	Code reference
Terminal	Printed immediately after each decision via formatExplanation()	src/agent/index.ts L119
Terminal (checkpoint block)	Printed again inside the signed checkpoint summary via formatCheckpointLog()	src/agent/index.ts L174
EIP-712 signature	keccak256(reasoning) is computed and included in the signed payload	src/explainability/checkpoint.ts L69
checkpoints.jsonl	Full reasoning string appended as JSON after every tick	src/agent/index.ts L193
Dashboard	Shown on each checkpoint card under the action badge	http://localhost:3000 (poll every 5s)

You'll see the first output in the terminal within 30 seconds of starting npm run run-agent (the agent warms up for 5 ticks collecting price samples, then starts making decisions). The default interval is set in src/agent/index.ts L42 and can be overridden with POLL_INTERVAL_MS in .env.

---

The formatExplanation() function

src/explainability/reasoner.ts L19–L51 wraps the decision + market context into a structured log line:

import { formatExplanation } from "./src/explainability/reasoner.js";

const explanation = formatExplanation(decision, market);
console.log(explanation);

Output for a BUY:

[2024-01-15T10:30:00.000Z] BUY XBTUSD — $100.00 @ $95,420.50
  Confidence: 78%
  Reason: Upward momentum: price rose 0.62% over last 5 ticks. Spread is tight at 0.003%. Buying.
  Market context: 24h high=96200, low=93800, VWAP=94980.20
  Spread: 0.0052% | Volume: 1204.50

Output for a HOLD:

[2026-03-27T11:02:50.000Z] HOLD XBTUSD @ $66,422.60
  Confidence: 50%
  Reason: No clear momentum (0.09% change). Holding current position.
  Market: bid=66421, ask=66421.1, spread=0.0002%, vol=2764.35

---

Swapping in an LLM (optional)

The demo runs MomentumStrategy — no LLM involved. Reasoning is generated directly from price arithmetic (src/agent/strategy.ts L61–L72). That's intentional: the template works out of the box without any API keys beyond Kraken.

When you're ready to replace the strategy with a model, the codebase includes a ready-to-wire LLMStrategy stub at src/agent/strategy.ts L90–L135:

// const response = await this.client.messages.create({
//   model: "claude-sonnet-4-6",
//   max_tokens: 500,
//   messages: [{
//     role: "user",
//     content: `You are a crypto trading agent. Here is the current market data:
//       Pair: ${data.pair}
//       Price: $${data.price}
//       24h High: $${data.high}, Low: $${data.low}
//       Volume: ${data.volume}
//       VWAP: $${data.vwap}
//
//       Respond with JSON: { action: "BUY"|"SELL"|"HOLD", amount: number, confidence: 0-1, reasoning: string }`
//   }]
// });

Uncomment and fill in your client — the reasoning field in the JSON response maps directly to TradeDecision.reasoning. The key constraint: reasoning must reference actual market data values (price, volume, VWAP). This makes the explanation auditable — anyone can cross-check the claim against the historical market data.

---

The formatCheckpointLog() function

src/explainability/reasoner.ts L56–L70 — when a checkpoint is generated, formatCheckpointLog() produces a structured summary for the terminal:

────────────────────────────────────────────────────────────────────────
CHECKPOINT — BUY XBTUSD
  Agent:     0xabc...def
  Timestamp: 2024-01-15T10:30:00.000Z
  Amount:    $100
  Price:     $95420.5
  Confidence: 78%
  Reasoning: Upward momentum: price rose 0.62% over last 5 ticks...
  Sig:       0x1a2b3c4d5e6f7890...1234567890
  Signer:    0xYourWalletAddress
────────────────────────────────────────────────────────────────────────

---

Reading a full tick in the terminal

Here's what one complete tick looks like, annotated:

[agent] XBTUSD @ $66,391.2                          ← live price fetch from Kraken

[2026-03-28T12:27:05.553Z] HOLD XBTUSD @ $66,391.20 ← formatExplanation() output
  Confidence: 50%                                    ← decision.confidence
  Reason: No clear momentum (-0.00% change).         ← decision.reasoning (from your strategy)
          Holding current position.
  Market: bid=66391.2, ask=66391.3,                 ← raw market data at decision time
          spread=0.0002%, vol=2287.42

────────────────────────────────────────────────────────────────────────
CHECKPOINT — HOLD XBTUSD                            ← formatCheckpointLog() output
  Agent:     1                                       ← agentId (ERC-721 token ID)
  Timestamp: 2026-03-28T12:27:05.000Z
  Amount:    $0                                      ← $0 for HOLD, non-zero for BUY/SELL
  Price:     $66391.2
  Confidence: 50%
  Reasoning: No clear momentum (-0.00% change).      ← same reasoning, now inside the signed payload
             Holding current position.
  Sig:       0x009aa74a5314926499...0d7940931c       ← EIP-712 signature over all of the above
  Signer:    0x13Ef924EB7408e90278B86b659960AFb00DDae61  ← agentWallet address
────────────────────────────────────────────────────────────────────────

[agent] Checkpoint posted to ValidationRegistry: 0xca62bb0d47f2b53a1a...  ← on-chain tx hash

The sequence within each tick is:

1. kraken.getTicker() — fetch live price from Kraken
2. strategy.analyze(market) — strategy returns a TradeDecision (including reasoning)
3. formatExplanation() — prints the human-readable summary
4. generateCheckpoint() — signs the decision with EIP-712; reasoning is hashed into the signature
5. formatCheckpointLog() — prints the signed checkpoint block
6. ValidationRegistry post — checkpoint hash submitted on-chain to Sepolia
7. fs.appendFileSync() — checkpoint appended to checkpoints.jsonl

---

The checkpoints.jsonl file

Every checkpoint is appended to checkpoints.jsonl at the project root. Each line is a JSON object:

{"agentId":"0x...","timestamp":1704067200,"action":"BUY","asset":"XBT","pair":"XBTUSD","amountUsd":100,"priceUsd":95420.5,"reasoning":"Upward momentum...","reasoningHash":"0x...","confidence":0.78,"signature":"0x...","signerAddress":"0x..."}

This file is your audit log. After a trading session you can:

• Review every decision and the reasoning behind it
• Verify any signature with verifyCheckpoint()
• Check that reasoning strings weren't tampered with using verifyReasoningIntegrity()

---

Template note

Why this matters: The explanation layer is already wired into the agent loop, you don't need to call it manually. Your strategy's reasoning field is the only input required. The stronger and more specific your reasoning strings, the more useful your agent's audit trail becomes — for debugging, for trust, and for building reputation over time.

---

Part 6: EIP-712 Signed Checkpoints

What problem this solves

Your agent writes "I bought BTC because the momentum was strong" to a log file. But a log file is just text, anyone could edit it. How do you prove that:

1. A specific agent made a specific decision
2. At a specific time
3. With a specific piece of reasoning
4. And that nothing was tampered with afterward?

EIP-712 signatures solve this. Every trade decision is cryptographically signed by the agent's private key over structured data that includes all of the above.

---

What EIP-712 is

EIP-712 is the Ethereum standard for signing typed structured data (as opposed to raw bytes). It produces human-readable signing prompts in wallets and prevents signature replay attacks across different contracts and chains.

A signature under EIP-712 proves:

• The signer held the private key at signing time
• The signed data has not been modified
• The signature was intended for this specific contract + chain (via the domain separator)

---

The checkpoint schema

src/explainability/checkpoint.ts L28–L41 defines the typed structure:

const domain = {
  name: "AITradingAgent",
  version: "1",
  chainId: 11155111,          // Sepolia
  verifyingContract: REGISTRY_ADDRESS,
};

const types = {
  TradeCheckpoint: [
    { name: "agentId",           type: "uint256" }, // ERC-721 token ID
    { name: "timestamp",         type: "uint256" },
    { name: "action",            type: "string"  },
    { name: "asset",             type: "string"  },
    { name: "pair",              type: "string"  },
    { name: "amountUsdScaled",   type: "uint256" }, // USD * 100
    { name: "priceUsdScaled",    type: "uint256" }, // USD * 100
    { name: "reasoningHash",     type: "bytes32" }, // keccak256(reasoning)
    { name: "confidenceScaled",  type: "uint256" }, // confidence * 1000
    { name: "intentHash",        type: "bytes32" }, // hash of the approved TradeIntent
  ],
};

Why reasoningHash instead of the full reasoning string?

• Strings can be arbitrarily long: hashing keeps the signed payload compact (checkpoint.ts L69)
• The hash is a commitment: if you have the hash and the original string, you can verify they match (verifyReasoningIntegrity())
• The full reasoning string is stored alongside the checkpoint in checkpoints.jsonl (index.ts L193)

---

Generating a checkpoint

src/explainability/checkpoint.ts L59–L67:

import { generateCheckpoint } from "./src/explainability/checkpoint.js";

const checkpoint = await generateCheckpoint(
  agentId,         // uint256 ERC-721 token ID
  decision,        // TradeDecision from your strategy
  market,          // MarketData at decision time
  signer,          // ethers.Wallet — the agent's signing key
  registryAddress, // AgentRegistry address (for domain separator)
  11155111         // Sepolia chain ID
);

// checkpoint.signature = "0x1a2b3c..."
// checkpoint.signerAddress = "0xYourWalletAddress"
// checkpoint.reasoningHash = keccak256(decision.reasoning)

Internally this calls wallet.signTypedData(domain, types, value): ethers.js v6's EIP-712 signing method.

---

Verifying a checkpoint

Anyone can verify a checkpoint without trusting any intermediary:

import { verifyCheckpoint, verifyReasoningIntegrity } from "./src/explainability/checkpoint.js";

// 1. Verify the signature recovers to the expected signer
const sigValid = verifyCheckpoint(
  checkpoint,
  registryAddress,
  11155111,
  expectedSignerAddress
);
console.log(`Signature valid: ${sigValid}`);  // true

// 2. Verify the reasoning string wasn't tampered with
const reasoningValid = verifyReasoningIntegrity(checkpoint);
console.log(`Reasoning hash matches: ${reasoningValid}`);  // true

Under the hood this uses ethers.verifyTypedData():

const recovered = ethers.verifyTypedData(domain, CHECKPOINT_TYPES, value, checkpoint.signature);
return recovered.toLowerCase() === expectedSigner.toLowerCase();

---

Reading checkpoints from checkpoints.jsonl

import * as fs from "fs";
import { verifyCheckpoint } from "./src/explainability/checkpoint.js";

const lines = fs.readFileSync("checkpoints.jsonl", "utf8").trim().split("\n");
const checkpoints = lines.map(l => JSON.parse(l));

for (const cp of checkpoints) {
  const valid = verifyCheckpoint(cp, registryAddress, 11155111, expectedSigner);
  console.log(`${new Date(cp.timestamp * 1000).toISOString()} | ${cp.action} ${cp.pair} | valid: ${valid}`);
}

---

What you can build on top of this

The signed checkpoint format is a foundation. With it you can:

• On-chain verification: a smart contract could call ecrecover to verify a checkpoint was produced by a registered agent before allowing an action
• Reputation scoring: aggregate checkpoint history to score agents by decision quality
• Dispute resolution: if someone claims the agent made a bad decision, the signed checkpoint is the ground truth
• Compliance: verifiable audit trail that specific reasoning led to specific trades

---

Template note

Why this matters: Checkpoint generation is automatic, the agent loop calls generateCheckpoint() after every decision, including HOLDs. Every action your agent takes is cryptographically signed and tied to its registered agentId. This is the foundation for building on-chain reputation: a verifiable, tamper-proof history of decisions that anyone can audit.

---

Part 7: Using This as a Reusable Template

The architecture in one picture

┌────────────────────────────────────────────────────────────────┐
│                     YOUR STRATEGY (swap here)                  │
│  implements TradingStrategy { analyze(MarketData): TradeDecision }  │
└──────────────────────────────┬─────────────────────────────────┘
                               │ TradeDecision
                               ▼
┌────────────────────────────────────────────────────────────────┐
│                     FIXED SCAFFOLDING                          │
│                                                                │
│  Identity     ERC-8004 AgentRegistry (Sepolia)                │
│  Vault        Vault.allocatedCapital[agentId]                 │
│  Risk         RiskRouter.validateTrade(agentId, size)         │
│  Exchange     Kraken REST API (paper or live)                 │
│  Explain      formatExplanation(decision, market)             │
│  Checkpoint   EIP-712 signTypedData → checkpoints.jsonl       │
└────────────────────────────────────────────────────────────────┘

Everything below the dashed line is provided by this template. You only need to implement analyze().

---

How to swap in your own strategy

Option A: Simple algorithmic strategy

Implement TradingStrategy directly:

// src/agent/my-strategy.ts
import { MarketData, TradeDecision, TradingStrategy } from "../types/index";

export class MyStrategy implements TradingStrategy {
  async analyze(data: MarketData): Promise<TradeDecision> {
    // Your logic here — technical indicators, ML model, anything
    const action = data.price > data.vwap ? "BUY" : "SELL";

    return {
      action,
      asset: "XBT",
      pair: data.pair,
      amount: 100,
      confidence: 0.7,
      reasoning: `Price ($${data.price}) is ${action === "BUY" ? "above" : "below"} VWAP ($${data.vwap.toFixed(2)}). ${action}.`,
    };
  }
}

Then in src/agent/index.ts L28 & L211, swap the strategy import:

// Before:
import { MomentumStrategy } from "./strategy";
const strategy = new MomentumStrategy(5, 100);

// After:
import { MyStrategy } from "./my-strategy.js";
const strategy = new MyStrategy();

That's it. Everything else — identity, vault, risk checks, Kraken execution, checkpoints — runs unchanged.

---

Option B: Claude API strategy

Full stub in src/agent/strategy.ts L90 — uncomment and fill in your client:

import Anthropic from "@anthropic-ai/sdk";
import { MarketData, TradeDecision, TradingStrategy } from "../types/index";

export class ClaudeStrategy implements TradingStrategy {
  private client = new Anthropic();

  async analyze(data: MarketData): Promise<TradeDecision> {
    const response = await this.client.messages.create({
      model: "claude-sonnet-4-6",
      max_tokens: 500,
      system: `You are a crypto trading agent. Respond ONLY with valid JSON matching:
        { action: "BUY"|"SELL"|"HOLD", amount: number, confidence: number, reasoning: string }
        reasoning must reference specific numbers from the market data.`,
      messages: [{
        role: "user",
        content: `Analyze: pair=${data.pair} price=${data.price} high=${data.high} low=${data.low} vwap=${data.vwap} volume=${data.volume}`,
      }],
    });

    const parsed = JSON.parse(response.content[0].type === "text" ? response.content[0].text : "{}");
    return {
      ...parsed,
      asset: data.pair.replace("USD", ""),
      pair: data.pair,
    };
  }
}

Add to .env: ANTHROPIC_API_KEY=your_key

---

Option C: Groq / Llama strategy

See also src/agent/strategy.ts L27 for the MomentumStrategy reference implementation:

import Groq from "groq-sdk";
import { MarketData, TradeDecision, TradingStrategy } from "../types/index";

export class GroqStrategy implements TradingStrategy {
  private client = new Groq({ apiKey: process.env.GROQ_API_KEY });

  async analyze(data: MarketData): Promise<TradeDecision> {
    const completion = await this.client.chat.completions.create({
      model: "llama-3.3-70b-versatile",
      messages: [
        {
          role: "system",
          content: `Trading agent. Return JSON: { action, amount, confidence, reasoning }`,
        },
        {
          role: "user",
          content: JSON.stringify({ pair: data.pair, price: data.price, high: data.high, low: data.low, vwap: data.vwap }),
        },
      ],
      response_format: { type: "json_object" },
    });

    const parsed = JSON.parse(completion.choices[0].message.content || "{}");
    return { ...parsed, asset: data.pair.replace("USD", ""), pair: data.pair };
  }
}

---

What teams can customize

Layer	Customizable?	How
Trading strategy / model	✅ Yes	Implement TradingStrategy
Trading pair	✅ Yes	TRADING_PAIR in .env
Poll interval	✅ Yes	POLL_INTERVAL_MS in .env
Risk parameters	✅ Yes	setRiskParams() call
Agent metadata	✅ Yes	Edit name/description/capabilities in register-agent.ts
ERC-8004 identity scheme	❌ Fixed	Same for all agents
Vault + RiskRouter contracts	❌ Fixed	Same contracts, per-agent config
Kraken API client	❌ Fixed	src/exchange/kraken.ts
EIP-712 checkpoint format	❌ Fixed	src/explainability/checkpoint.ts

---

Checklist for a new team

1. git clone https://github.com/Stephen-Kimoi/ai-trading-agent-template && cd ai-trading-agent-template
2. npm install
3. cp .env.example .env and fill in keys
4. npx hardhat run scripts/deploy.ts --network sepolia — deploy contracts
5. Add all 5 contract addresses to .env
6. npm run register — register your agent on-chain
7. Add AGENT_ID to .env
8. Write your strategy in src/agent/my-strategy.ts
9. Swap the strategy import in src/agent/index.ts
10. Run the agent and dashboard in two terminals:

npm run run-agent    # Terminal 1
npm run dashboard    # Terminal 2 → http://localhost:3000

---

Going to production

When you're ready to trade for real:

1. Set KRAKEN_SANDBOX=false in .env
2. Ensure your vault has allocated capital for your agent
3. Set sensible risk params via setRiskParams()
4. Monitor the dashboard (npm run dashboard) for live decisions and signed checkpoints
5. All checkpoints are also written to checkpoints.jsonl for offline audit

---

Dashboard

The project ships with a live web dashboard (scripts/dashboard.ts) that reads from checkpoints.jsonl and auto-refreshes every 5 seconds:

npm run dashboard   # → http://localhost:3000

It shows:

• Live BTC price with tick-by-tick change
• Last decision (HOLD / BUY / SELL) with colour indicator
• Price chart of the last 20 ticks
• Agent info — agentId, wallet, pair, checkpoint count
• Checkpoint feed — every decision as a card with reasoning, confidence bar, and truncated EIP-712 signature

Run it alongside npm run run-agent for a complete view of the agent in action.

---

Congratulations — you have a production-ready AI trading agent with on-chain identity, risk controls, cryptographic explainability, and a live dashboard.
